DFI Series

Question 1

Q: What professional certificates do you have？

Answer

A: We pay great attention with the quality of our products and we have many quality certificates: ISO9001, ISO14001, CE European Union certification certificate, ROHS certificate etc.

Question 2

Q: Can I get a sample?

Answer

A: Yes, sample is available. If you are interested, you can contact us by e-mail (info@shac-europe.com) to get more photos and information.

Question 3

Q: Delivery Date?

Answer

A: Normal order delivery of linear motion products is generally controlled within 1-2 months.
Normal order delivery for linear unit and higher precision products is generally controlled within 7-15 working days.

Question 4

Q: What is your shipping optional?

Answer

A: Our cooperating transportation companies include DHL, TNT, UPS, etc. Sea transportation, air transportation and express delivery are all available. If you have a specific carrier, please let us know when you place the order.

Question 5

Q: Whether to accept customized products?

Answer

A: You can contact us by e-mail (info@shac-europe.com ) and we will recommend the most suitable project according to your requirements.

Question 6

Q: What is your payment methods?

Answer

A: T/T in advance.

Question 7

Q: Which countries do you have distributor?

Answer

A: SHAC agent in Asia: Singapore, Japan, India
SHAC agent in Europe: Hungary, Turkey, Israel
SHAC agent in South America: Brazil

Question 8

Q: Where is your main market?

Answer

A: SHAC do quite well in Europe, Asia and South America, also China is a potential market for us. Now SHAC’s distributors have covered more than 32 country and regions.

Question 9

Q: Can I be a SHAC agent?

Answer

A: We are really looking forward to having you as a solid partner of SHAC. Please contact us by e-mail (info@shac-europe.com ) , we can start talk and get to know more about each other.

Circulation type	Model		Characteristic
Circulation type	Single Nut	Double Nuts	Characteristic
Internal Circulation type	SFK SFNU SFNI SCI	DFNU DFNI	•Dedicated diameter of screw takes only little space. •Applicable to those with smaller lead / the outside diameter of the screw
External Circulation type	SFV XFV	DFV	•Economy •Applicable to larger lead and diameter. •Applicable for high loading purpose.
End-caps Circulation type	SFS SFY	DFS	•Suitable for high speed positioning

	Model No.	d	l	Dimension											Load Rating
	Model No.	d	l	Da	D	A	B	L	W	H	X	Y	Z	Q	n	Ca(kgf)	Coa(kgf)
☆	DFI1605-4	16	5	3.175	30	49	10	10	39	34	4.5	8	4.5	M6x1	1×4	1127	2288
☆	DFI2005-4	20	5	3.175	34	57	11	101	45	40	5.5	9.5	5.5	M6x1	1×4	1268	2991
☆	DFI2505-4	25	5	3.175	40	63	11	101	51	46	5.5	9.5	5.5	M6x1	1×4	1420	3872
☆	DFI2510-4	25	10	4.762	46	72	12	145	58	52	6.5	11	6.5	M6x1	1×4	2415	5543
☆	DFI3205-4	32	5	3.175	46	72	12	102	58	52	6.5	11	6.5	M8x1	1×4	1604	5103
	DFI3210-4	32	10	6.35	54	88	15	162	70	62	9	14	8.5	M8x1	1×4	3924	9152
	DFI4005-4	40	5	3.175	56	90	15	102	72	64	9	14	8.5	M8x1	1×4	1786	6512
	DFI4010-4	40	10	6.35	62	104	18	165	82	70	11	17.5	11	M8x1	1×4	4417	11669
	DFI5010-4	50	10	6.35	72	114	18	171	92	82	11	17.5	11	M8x1	1×4	4947	15488
	DFI6310-4	63	10	6.35	85	131	22	182	107	95	14	20	13	M8x1	1×4	5586	20417
	DFI8010-4	80	10	6.35	105	150	22	182	127	115	14	20	13	M8x1	1×4	6219	26049
Note:with sign ☆ can poduce left helix

DFNI Ball Screw Nut

Ball Screw Nut

DFI Series

Features:

Size Table of DFNI Screws
