SFA series

Question 1

Q: What professional certificates do you have？

Answer

A: We pay great attention with the quality of our products and we have many quality certificates: ISO9001, ISO14001, CE European Union certification certificate, ROHS certificate etc.

Question 2

Q: Can I get a sample?

Answer

A: Yes, sample is available. If you are interested, you can contact us by e-mail (info@shac-europe.com) to get more photos and information.

Question 3

Q: Delivery Date?

Answer

A: Normal order delivery of linear motion products is generally controlled within 1-2 months.
Normal order delivery for linear unit and higher precision products is generally controlled within 7-15 working days.

Question 4

Q: What is your shipping optional?

Answer

A: Our cooperating transportation companies include DHL, TNT, UPS, etc. Sea transportation, air transportation and express delivery are all available. If you have a specific carrier, please let us know when you place the order.

Question 5

Q: Whether to accept customized products?

Answer

A: You can contact us by e-mail (info@shac-europe.com ) and we will recommend the most suitable project according to your requirements.

Question 6

Q: What is your payment methods?

Answer

A: T/T in advance.

Question 7

Q: Which countries do you have distributor?

Answer

A: SHAC agent in Asia: Singapore, Japan, India
SHAC agent in Europe: Hungary, Turkey, Israel
SHAC agent in South America: Brazil

Question 8

Q: Where is your main market?

Answer

A: SHAC do quite well in Europe, Asia and South America, also China is a potential market for us. Now SHAC’s distributors have covered more than 32 country and regions.

Question 9

Q: Can I be a SHAC agent?

Answer

A: We are really looking forward to having you as a solid partner of SHAC. Please contact us by e-mail (info@shac-europe.com ) , we can start talk and get to know more about each other.

Circulation type	Model		Characteristic
Circulation type	Single Nut	Double Nuts	Characteristic
Internal Circulation type	SFK SFNU SFNI SCI	DFNU DFNI	•Dedicated diameter of screw takes only little space. •Applicable to those with smaller lead / the outside diameter of the screw
External Circulation type	SFV XFV	DFV	•Economy •Applicable to larger lead and diameter. •Applicable for high loading purpose.
End-caps Circulation type	SFS SFY	DFS	•Suitable for high speed positioning

Model no.	d	l	Da	Dimension										Load Rating		K
Model no.	d	l	Da	D	A	E	B	L	W	H	X	Q	n	Ca(kgf)	Ca(kgf)	kgf/μm
SFA0802 – 3.8	8	2	1.2	14	27	3	5	17.5	21	18	4 – Φ3.4	/	3.8*1	208	419	13
SFA0802.5 – 3.8	8	2.5	1.2	14	27	3	5	20	21	18	4 – Φ3.4	/	3.8*1	207	418	13
SFA0805 – 1.8	8	5	1.2	14	27	3	5	19	21	18	4 – Φ3.4	/	1.8*1	107	195	6
SFA1004 – 3.8	10	4	2	26	46	4	10	30	36	28	4 – Φ4.5	M6*1	3.8*1	439	827	16
SFA1006 – 2.8	10	6	1.588	18	35	5	6	26	27	22	4 – Φ4.5	/	2.8*1	247	482	11
SFA1012 – 1.8	10	12	1.588	18	35	5	6	32	27	22	4 – Φ4.5	/	1.8*1	164	311	7
SFA1205 – 2.8	12	5	2.5	24	40	5	10	30	32	30	6 – Φ4.5	M6*1	2.8*1	487	886	14
SFA1210 – 2.8	12	10	2.5	24	40	5	10	42	32	30	6 – Φ4.5	M6*1	2.8*1	472	865	13
SFA1220 – 1.8	12	20	2.5	24	40	5	10	50	32	30	6 – Φ4.5	M6*1	1.8*1	313	578	8
SFA1605 – 3.8	14.8	5	2.778	28	48	5	10	31	38	40	6 – Φ5.5	M6*1	3.8*1	821	1706	22
SFA1610 – 2.8	14.8	10	2.778	28	48	5	10	42	38	40	6 – Φ5.5	M6*1	2.8*1	643	1311	17
SFA1616 – 1.8	14.8	16	2.778	28	48	5	10	43	38	40	6 – Φ5.5	M6*1	1.8*1	423	818	11
SFA1616 – 2.8	14.8	16	2.778	28	48	5	10	59	38	40	6 – Φ5.5	M6*1	2.8*1	618	1272	16
SFA1620 – 1.8	14.8	20	2.778	28	48	5	10	50	38	40	6 – Φ5.5	M6*1	1.8*1	424	841	11
SFA2005 – 3.8	20	5	3.175	36	58	7	10	33	47	44	6 – Φ6.6	M6*1	3.8*1	1135	2655	29
SFA2010 – 3.8	20	10	3.175	36	58	7	10	52	47	44	6 – Φ6.6	M6*1	3.8*1	1160	2765	299
SFA2020 – 1.8	20	20	3.175	36	58	7	10	52	47	44	6 – Φ6.6	M6*1	1.8*1	585	1268	14
SFA2020 – 2.8	20	20	3.175	36	58	7	10	72	47	44	6 – Φ6.6	M6*1	2.8*1	855	1972	21
SFA2505 – 3.8	25	5	3.175	40	62	7	10	33	51	48	6 – Φ6.6	M6*1	3.8*1	1239	3219	33
SFA2510 – 3.8	25	10	3.175	40	62	7	10	52	51	48	6 – Φ6.6	M6*1	3.8*1	1263	3333	35
SFA2520 – 2.8	25	20	3.175	40	62	7	12	76	51	48	6 – Φ6.6	M6*1	2.8*1	943	2400	25
SFA2525 – 1.8	25	25	3.175	40	62	7	12	60	51	48	6 – Φ6.6	M6*1	1.8*1	647	1578	16
SFA2525 – 2.8	25	25	3.175	40	62	7	12	85	51	48	6 – Φ6.6	M6*1	2.8*1	947	2454	25
SFA3205 – 3.8	32	5	3.175	50	80	9	12	35	65	62	6 – Φ9	M6*1	3.8*1	1407	4347	41
SFA3210 – 3.8	32	10	3.969	50	80	9	13	53	65	62	6 – Φ9	M6*1	3.8*1	1883	5234	42
SFA3220 – 2.8	32	20	3.969	50	80	9	13	72	65	62	6 – Φ9	M6*1	2.8*1	1459	3954	32
SFA3232 – 1.8	32	32	3.969	50	80	9	13	78	65	62	6 – Φ9	M6*1	1.8*1	962	2471	20
SFA3232 – 2.8	32	32	3.969	50	80	9	13	110	65	62	6 – Φ9	M6*1	2.8*1	1406	3844	31
SFA4005 – 3.8	38	5	3.175	63	93	9	15	39	78	70	8 – Φ9	M8*1	3.8*1	1544	5474	49
SFA4010 – 3.8	38	10	6.35	63	93	9	14	57	78	70	8 – Φ9	M8*1	3.8*1	3863	10046	53
SFA4020 – 2.8	38	20	6.35	63	93	9	15	78	78	70	8 – Φ9	M8*1	2.8*1	3815	9950	52
SFA4040 – 1.8	38	40	6.35	63	93	9	15	96	78	70	8 – Φ9	M8*1	1.8*1	1980	4783	25
SFA4040 – 2.8	38	40	6.35	63	93	9	15	136	78	70	8 – Φ9	M8*1	2.8*1	2895	7441	38
SFA5005 – 3.8	48	5	3.175	75	110	10.5	15	42	93	85	8 – Φ11	M8*1	3.8*1	1689	6883	58
SFA5010 – 3.8	48	10	6.35	75	110	10.5	18	57	93	85	8 – Φ11	M8*1	3.8*1	4314	12873	63
SFA5020 – 2.8	48	20	6.35	75	110	10.5	18	98	93	85	8 – Φ11	M8*1	2.8*1	4399	13333	66
SFA5050 – 1.8	48	50	6.35	75	110	10.5	18	117	93	85	8 – Φ11	M8*1	1.8*1	2254	6311	31
SFA5050 – 2.8	48	50	6.35	75	110	10.5	18	167	93	85	8 – Φ11	M8*1	2.8*1	3296	9817	47

SFA Series

SFA series

Size Table of SFA Screws
